BATTERY TESTER

The Midtronics MDX-600 Series combines 30 years of experience and innovation gained from selling essential tools to nearly every car and truck OEM in the world. With industry standard conductance technology for battery testing, the MDX Series is:

SAFE: Worry-free operation anywhere, even in front of customers
FAST & ACCURATE: Testing of the battery or electrical system in seconds
SIMPLE: Proven user interface eliminates guesswork and user error to provide an accurate analysis every time

ApplicationsFeaturesBenefitsSpecificationsCatalogueRequest a Quote
  • Analyzes 12V and 24V Starting and Charging current
  • Battery tester for 6 and 12V Regular flooded and AGM batteries
  • Start-Stop testing technology
  • Conductance Profiling
  • Multiple vehicle applications, and Rating systems
  • Large back-lit screen and improved user interface
  • Integrated printer option
  • Improved removable cable design
  • Field replaceable cables
  • Reverse Polarity Protection
  • New Battery test
  • Battery test, and starting and charging system voltage test, with integrated printer
  • Can check various Batteries chemistries like Lead-Acid, Gel, AGM and EFB
  • 10ft. Long Battery Cable for single man operation
  • Single Printout for the Battery and Auto Electrical test
  • Special Algorithm to test all kinds of Regular & Low Sp.Gravity Indian and Imported automotive batteries.
  • Simplify usability with multi-lingual display
  • Save time and money by improving battery and electrical diagnostic productivity
  • Improves customer service by reducing wait times
  • Increases sales by proactively testing batteries and electrical systems
  • Increases customer satisfaction by identifying potential problems before they occur
  • Analyzes 12V and 24V Starting and Charging current
  • Battery tester for 6 and 12V Regular flooded and AGM batteries
  • User friendly
S.no Parameter Specification
1 Test range Batteries 20 to 200 Ah
2 Voltage range 1VDC to 30 VDC
3 Cable length 3M
4 Dimensions (L x W x H) 270 x 100 x 50 mm
5 Unit weight 1 Kg approx.
6 Display 5-Line text/Graphical Backlit display

Uses the power of the battery under test and 6AA internal batteries
